Description
Transmission Installation cost (optional): $1500.00 (Effective 08/15/2024) – includes removal of old unit, hot flush of transmission cooler/lines and installation of MPT transmission with transmission fluid. Contact us to check scheduled installation lead time before ordering. To schedule an installation time, a non refundable deposit of $500.00 is required.
Prior to purchasing, please review our 68RFE Pre-Purchase Instructions / Criteria
-SFI spec 29.3 billet flexplate
-Suncoast triple disc torque converter with billet cover
-Muldoon's rebuild kit with upgraded clutch packs
-Increased 2C clutch count
-Steel center support with additional 4C clutches
-Billet 2C apply piston
-Billet 4C retainer
-Billet input shaft with overdrive clutch direct oiling
-Revmax 850 series overdrive drum with 18 clutch overdrive configuration
-Billet overdrive hub
-MPT valve body with upgraded solenoid switch valve
-Billet accumulators
-Upgraded accumulator cover with additional hardware
-DNJ billet channel plate
-Rebuilt oil pump with updated TCC Limit, PR, TCC switch valves are checked and repaired to ensure hydraulic integrity
-New electronic solenoid pack
-Upgraded low/ reverse sprag (Roller Style)
-Tig-welded input planetary
-New speed sensors and line pressure sensor
-New pistons, bushings and bearings
-New MOPAR filters
-Deep pan
- Dynamometer tested for quality control
Rated for Trucks Making up to 900 WHP
If truck doesn't already have one, we will need to install a thermostatic bypass (additional $109.00).
Click here to view our 68RFE Installation Instructions.
